18-1 Kukko Pulling Device for use with Series 17, 15, 18-AS and 18-A
Kukko pulling device for use with series 17, series 15, series 18-AS and series 18-A. Leg length 60-150mm, leg width 112-200mm
Regular price
From
£113.23
£94.36 exc.VAT
Couldn't load pickup availability
Description
For use with series 15 and 17 separators.
The pulling device can be combined with the series 18-0-AS screw adapter to remove parts with threaded holes.
Mechanical pressure screw.
Milled thread treated with special coating.
Advantage
Ultimate stability when removing, as the separator and pulling device are screwed firmly together.
Almost all components available as replacement parts, time-saving order process thanks to numbering system.
How it works
The wedge-shaped separator jaws are secured underneath the component to be removed.
For removal, the tension bolts on the pulling device have to be screwed into the separator.
Use the knurled screws to position the cross-beam.
Tightening of the pressure screw and the resulting pressure removes the part from the shaft.
Goes with
15-1 Separators
17-1 Separator with quick clamping pressure spindle
Spare part of
15-A Separating-set
17-A Separating-set with quick clamping pressure spindle
Part of
15-A Separating-set
17-A Separating-set with quick clamping pressure spindle
EVLW-1-KFZ Merchandiser, automotiv pullers
EVLW-1-NFZ Merchandiser, automotiv pullers
EVLW-1-INDUSTRIE Display
WT-019 Puller product range - separating
Accessories
18-0-AS Set of screw adapters
18-003A Internal Extracting
18-004A Internal Extracting
18-005A Internal Extracting
18-006A Internal Extracting
18-008A Internal Extracting
18-010A Internal Extracting
18-012A Internal Extracting
18-016A Internal Extracting
19-1-P 2 extensions for pulling devices (pair)
Safety information
If several parts have to be removed, always follow a step-by-step process. Do not remove several parts at the same time.
The separator blades support surfaces must always sit fully beneath the part to be removed.
Do not use any electrical or pneumatic servo screwdrivers or hammer drills.
Protective blanket required.
Protective goggles required.
