7000CTRDULP3 NSK Super Precision Angular Contact Bearing 10x26x8mm (set of 2)
NSK High precision angular contact ball bearing with phenolic cage, 15 degree contact angle, can be paired universal face to face, back to back or in tandem, light preload 10mm inside x 26mm outside x 8mm wide
Regular price
£156.70
inc.VAT
£130.58 exc.VAT
FREE UK MAINLAND DELIVERY ON ORDERS OVER £50
Couldn't load pickup availability
High Precision Angular Contact Ball Bearings (standard series) have a line connecting the contact points drawn in the radial direction which is called the contact angle. This contact angle makes the bearing suitable for accommodating radial loads, single direction axial loads and a combination of both, these bearings are generally used in pairs but can also be used in triplex sets, quadruplex sets or multiplex sets,
70xx, 72xx and 79xx series have three types of contact angle 15 degree (C), 25 degree (A5) and 30 degree (A), all come with two types of cage design either phenolic (TR) or polyamide (TYN),
CTR = 15 Degree contact angle
DU = Pair of bearings paired universal
L= Light preload
P3 = Precision rating
d: 10mm
D: 26mm
B: 8mm
Basic load ratings: dynamic 5.30kn, static 2.49kn
Permissible axial load: 2.16kn
Contact angle (degree) 15
Factor: 12.6fo
Effective load center: 6.4mm
Mass: 0.0019kg
Limiting speed grease: 63 900
Limiting speed oil: 97 300
70xx, 72xx and 79xx series have three types of contact angle 15 degree (C), 25 degree (A5) and 30 degree (A), all come with two types of cage design either phenolic (TR) or polyamide (TYN),
CTR = 15 Degree contact angle
DU = Pair of bearings paired universal
L= Light preload
P3 = Precision rating
d: 10mm
D: 26mm
B: 8mm
Basic load ratings: dynamic 5.30kn, static 2.49kn
Permissible axial load: 2.16kn
Contact angle (degree) 15
Factor: 12.6fo
Effective load center: 6.4mm
Mass: 0.0019kg
Limiting speed grease: 63 900
Limiting speed oil: 97 300
