GK10DO Dunlop Spherical Plain Bearing with Rod End Housing 10mm Bore
Dunlop Spherical plain steel 10mm Bore with Rod End Housing.
Regular price
£4.85
inc.VAT
£4.04 exc.VAT
All prices exclude VAT unless otherwise stated
FREE UK MAINLAND DELIVERY ON ORDERS OVER £50
Couldn't load pickup availability
The GK DO Series is a 3 piece metric range of spherical plain bearings comprising weldable rod end housing with dowel pin. Ball and race slinding surfaces are phosphate treated for increased lubrication. There is a lubrication groove provided on the raceway along with a grease nipple on the rod end housing for applications that require re-lubrication after installation.
Material Specifications:
Rod End Housing: Weldable Steel, phosphate with a dowel pin at the base of the housing.
Bearing: Bearing Steel 100Cr6, Hardened and Manganese Phosphate.
Features:
Metric bore sizes
Low cost
Maintenance required
Possible Applications:
Light to heavy industrial/mechanical applications
Construction equipment
Agricultural equipment
Hydraulic applications
Temperature Range:
-54C to +121C
Specification:
ELV and RoHS compliant
d: 10
d1: 13.2
B: 9
C1: 7
dk: 16
d2: 29
L4: 38.5
h2: 24
L7: 15
L8: 1.5
d3: 3
d4: 15
D: 19
Load Ratings
Dynamic 8.15 kN
Static: 15.6 kN
