SP-4-SS Stainless Steel Double Split 1/4" Bore Shaft Collar 6.35 x 15.88 x 7.94mm

In stock
Double split 1/4 inch shaft collar type CADB in Stainless Steel supplied with clamp bolts.

$8.00 exc.VAT
🚚 Free UK Mainland Delivery Over £50 ex VAT

Product details

  • Quality Budget
  • Vendor BKL Brand
  • SKU SP-4-SS
  • Inside diameter (d) 6.35mm
  • Outside diameter (D) 15.88mm
  • Width (B) 7.94mm
A split two part assembly reducing downtime and labour requirements by facilitating quick and easy fitting and removal. Bore A: 6.35mm (1/4") Outside Dia B: 15.88mm (5/8") Width C: 7.94mm (5/16") Set Screw: 2BA Tolerances Diameter A (4mm - 6mm) +0.05mm / +0.00mm Diameter A... Read full description ↓ Show less ↑
A split two part assembly reducing downtime and labour requirements by facilitating quick and easy fitting and removal.

Bore A: 6.35mm (1/4")
Outside Dia B: 15.88mm (5/8")
Width C: 7.94mm (5/16")
Set Screw: 2BA

Tolerances
Diameter A (4mm - 6mm) +0.05mm / +0.00mm
Diameter A (8mm - 28mm) +0.07mm / +0.00mm
Diameter A (30mm - 80mm) +0.12mm / +0.00mm
Diameter B +0.20mm / -0.20mm
Length C +0.08mm / +0.25mm
