SP-6-SS Stainless Steel Double Split 3/8" Bore Shaft Collar 9.53 x 19.05 x 9.53mm

In stock
Double split 3/8 inch shaft collar type CADB in Stainlesss Steel plated supplied with clamp bolts.
Regular price £6.00 inc.VAT
£5.00 exc.VAT
🚚 Free UK Mainland Delivery Over £50 ex VAT

Product details

  • Quality Budget
  • Vendor BKL Brand
  • SKU SP-6-SS
  • Inside diameter (d) 9.53mm
  • Outside diameter (D) 19.05mm
  • Width (B) 9.53mm
A split two part assembly reducing downtime and labour requirements by facilitating quick and easy fitting and removal. Bore A: 9.53mm (3/8") Outside Dia B: 19.05mm (3/4") Width C: 9.53mm (3/8") Set Screw: 1/4BSW Tolerances Diameter A (4mm - 6mm) +0.05mm / +0.00mm Diameter A... Read full description ↓ Show less ↑
A split two part assembly reducing downtime and labour requirements by facilitating quick and easy fitting and removal.

Bore A: 9.53mm (3/8")
Outside Dia B: 19.05mm (3/4")
Width C: 9.53mm (3/8")
Set Screw: 1/4BSW

Tolerances
Diameter A (4mm - 6mm) +0.05mm / +0.00mm
Diameter A (8mm - 28mm) +0.07mm / +0.00mm
Diameter A (30mm - 80mm) +0.12mm / +0.00mm
Diameter B +0.20mm / -0.20mm
Length C +0.08mm / +0.25mm
